PART I: Investigating Buffers

This is part of our Virtual Buffers Lab series: Understanding, Making, and Using Buffers.

This lab includes two short experiments to discover the properties of buffer solutions.


Learning Objectives

Learning Objectives for Part I: Investigating Buffers

Students will be able to…

  • Identify the independent (manipulated) and dependent (responding) variables in a scientific investigation.
  • Draw conclusions about the relationship between two variables using quantitative data.
  • Describe the chemical function of a buffer solution.
  • Identify properties that affect the effectiveness of a buffer.

Key Vocabulary

  • Independent (Manipulated) Variable
  • Dependent (Responding)
  • Conjugate acid/base pair
  • Concentration
  • pH
  • Buffer



Documents


Part I: Investigating Buffers

Introduction

This activity is a lab investigation which addresses two scientific questions. A scientific question always asks how a manipulated, or independent, variable affects a responding, or dependent, variable. For example, a scientist could ask “How does the wingspan on a paper airplane affect how far it can fly?” In this case, the independent variable, what is being tested, is the wingspan; and the dependent variable, what is being measured, is how far it can fly.

Scientific Question Format: How does INDEPENDENT VARIABLE (IV) affect DEPENDENT VARIABLE (DV)?

Two scientific questions regarding acid-base buffer solutions will be investigated. An acid-base buffer solution (ie. buffer) is a solution that contains a conjugate acid-base pair–that is when the acid undergoes a reaction, it turns into its conjugate base; and when the base undergoes a reaction it turns into its conjugate acid.

Extensive knowledge about the chemistry of acids and bases or the concept of pH are not required to complete and learn something from this activity. However, a familiarity with terms is helpful.

Acids and bases are chemical substances that react with each other to form a more neutral substance. The acidity (acid) or alkalinity (base) of a substance can be determined by measuring its pH, which ranges anywhere on a scale between 0 to 14. Acids have a pH less than 7 and bases have a pH greater than 7. A pH of 7 is considered neutral.



Activity

Question 1: How does the concentration of buffer components in a solution affect the change in pH when a strong acid or strong base is added?




Data Table 1 - Investigating changes in pH based on concentrations of buffer components.

Buffer Components

IV- Concentration of buffer components

DV- Change in pH when a strong acid or base is added

With 0.001 mol HCl

With 0.001 mol NaOH

pH

𝚫pH

(final pH - initial pH)

pH

𝚫pH

(final pH - initial pH)

HNO3 + NaNO3

Click for video: 0.1 M

pH =

Video: Add HCl

pH =



Video: Add NaOH

pH =



Click for video: 1.0 M

pH =

Video: Add HCl

pH =



Video: Add NaOH

pH =



HC2H3O2 + NaC2H3O2

Click for video: 0.1 M

pH =

Video: Add HCl

pH =



Video: Add NaOH

pH =



Click for video: 1.0 M

pH =

Video: Add HCl

pH =



Video: Add NaOH

pH =



NH4Cl + NH4OH

Click for video: 0.1 M

pH =

Video: Add HCl

pH =



Video: Add NaOH

pH =



Click for video: 1.0 M

pH =

Video: Add HCl

pH =



Video: Add NaOH

pH =





Analysis 1:

Describe the relationship between the concentration of the buffer components and the change in pH when an acid or base is added.




Question 2: How does the amount of the strong acid or strong base being added affect the change in pH of a buffer solution?




Data Table 2 - Investigating changes in pH based on amount of added acid/base.

Buffer Components

IV- Amount of strong acid or strong base being added to buffer

DV- Change in pH of the buffer solution

HCl

NaOH

pH

𝚫pH

(final pH - initial pH)

pH

𝚫pH

(final pH - initial pH)

0.1 M HNO3 + 0.1 M NaNO3

Click to watch video

pH =

0.001 mol

Video: Add HCl

pH =



Video: Add NaOH

pH =



0.010 mol

Video: Add HCl

pH =



Video: Add NaOH

pH =



0.1 M HC2H3O2 + 0.1 M NaC2H3O2

Click to watch video

pH =

0.001 mol

Video: Add HCl

pH =



Video: Add NaOH

pH =



0.010 mol

Video: Add HCl

pH =



Video: Add NaOH

pH =



0.1 M NH4Cl + 0.1 M NH4OH

Click to watch video

pH =

0.001 mol

Video: Add HCl

pH =



Video: Add NaOH

pH =



0.010 mol

Video: Add HCl

pH =



Video: Add NaOH

pH =





Analysis 2:

Describe what happened to the change in pH when different amounts of strong acid or strong base were added to the solutions.



Navigate to the different pages of the Virtual Buffer Lab series: Understanding, Making, and Using Buffers
Click here to go to the  main page: Understanding, Making, and Using Buffers Click here to go to part 2 Click here to go to part three
Click her to go to part four



This lab was created with support from the Ren Research group at Purdue University with funding from the National Science Foundation grant NSF CHE 2102049.
